TrolMaster Program Device Station

item 615071 642091

🌱 TrolMaster(DSP-2) 240V Hydro-X Program Device Station

The TrolMaster DSP-2 program device module (timer module) works as a multi-function timer. The DSP-2 allows the user to easily connect any device that needs to be controlled by TIME to the Hydro-x. Any device that is 10-amps at 240 volts or less can be controlled by the DSP-2.

The DSP-2 works as a multi-function irrigation timer on the Aqua-X. The DSP-2 can be set to activate at a specific time(s) of day or night and configured to function as a recycling timer with or without a maximum number of cycles setting. The DSP-2 can also be used as a “master pump” controller on the Aqua-x. A master pump would be plugged into the DSP-2. When connected to the Aqua-x 24vac module, the DSP-2 will automatically turn on the pump when any of the 24vac irrigation zones are activated.

Features & Benefits:

• LED Indicator
• Attaching Plug
• RJ12 Cable Socket
• Address Assignment
• Plug & Play

Package Content:

• 1 x Device Station
• 1 x 16ft RJ12 Cable
• 1 x 4ft RJ12 Cable
• 1 x RJ12 T-Splitter

Specification:

• Input Voltage : 100~240 VAC, 50/60Hz
• Output Current : 10A
• Output Voltage : 100~240 VAC, 50/60Hz
• Working Temperature : 32-122°F
• Working Humidity : ≤90%
• Package Dimensions : 85mm(L) x 80mm(W) x 90mm(H)
• G.W. per pack : 0.34kgs
